The SPuMP is a 2 ml syringe pump operated by a step-motor. The syringe reservoir is temperature controlled. Up to 4 SPuMP-s can be separately controlled from one main controller. The D-Pump is a diaphragm pump with temperature-controlled 1.2 ml reservoir. It is hydraulically driven by a SPuMP, acting as an accurate hydraulic driver. The Control board, manifold and valve systems enable independent Operation of 4 SPuMPS, each driving two D-Pumps, acting together as a Multiplexed pump, where each D-Pump is operated independently with repeating pumping-refilling SpacePharma’s Fluid management system has concluded 6 tours to the International space station and 3 parabolic flights.
Our Labs
SPmg
Robust, simple system for free-orbit satellite and ISS modules SPmg is a 2U system capable of performing 4 experiments. It is equipped with a 600 microliter stirred reactor, a fluorescence microscope and visible light spectrometer. The lab is a closed system where the waste is stored in a volume-saving manner.
ENVIRONMENT
Temperature: 4-37* °C.
Active heaters are placed in order to prevent liquid freezing.
Pressure: 1 bar.
Radiation: Shielded
Environmental Monitoring:
Temperature reading accuracy: ±0.25 °C.
Pressure reading accuracy: ±2%
Radiation sensor sensitivity: 5.9 cpm/µSv/h
FLUID HANDLING
12 reservoirs of 1 ml each (3 for each experiment) These reservoirs also perform system purging between experiments.
4 mixing chambers – one for each experiment.
Reaction chamber – 600 micro-liters with speed-adjusted stirrer (60-300 RPM).
The reaction chamber is observed by the analytical system.
CHARACTERIZATION CAMERA
Camera:
Color filter array: RGB Bayer pattern.
Bit depth: 10 bit.
Dynamic range: 61 dB.
(Ability to compress to jpg images from raw format)
Active pixels: 2,048H x 1,536V.
Pixel size: 3.2μm x 3.2μm.
Microscope :
Field of view: 1.28 x 0.96 mm2.
Magnification: x5.
Pixel resolution: 0.64 µm.
Depth of field: 25 µm.
Software Controlled Adjustable Focus Step:
size: 10 µm.
Total range: 1300 µm.
CHARACTERIZATION SPECTROMETER
Spectrometer:
Wavelength: 420-750 nm.Optical resolution: 1.5 nm FWHM.
The SPmg has concluded one tour to the ISS. A second unit is active for over two years in a free-orbit satellite.
The heart of the lab
Modern Times
The factory of the futureModern Times is a large capacity system for either performing multiple experiments (as in factorial design tests) or for manufacturing industrial quantities. Design to be flown onboard Unmanned spacecraft.
SPECIFICATIONS
24U – 20*30*40
CMFour production lines
44 flow reactors
Advanced flow handling system with more than 36 pumps
Visible and fluorescence microscopy
Spectrometer and Fluorimeter
Active temperature control with different temperature zones
Advanced communication
